Product Model
FT-CJ18
Product Introduction
Shouguang Feitian Electronics Co., Ltd. is a high-tech enterprise specializing in the design, research and development and production of piezoelectric ceramic products. The company has a R & D team with rich experience, employs many well-known domestic experts in the piezoelectric ceramic industry, and maintains good cooperative relations with Shandong University, Tsinghua University, Chinese Academy of Sciences, Shanghai Silicate Research Institute and other units.
Product Parameters
Product Name | FT-CJ18 |
|---|---|
Product Category | integrated sending and receiving |
center frequency | 200.0?KHz±4% |
Capacitance | 450pF±20% |
blind area | 80cm |
Test distance (reference value) | 1m |
Direction angle (reference value) | 10°±2°(-6dB) |
Resolution (reference value) | 1mm |
Shell material | copper shell/nylon |
Operating voltage | 10-30V?DC |
Working temperature | -20 °c ~ 80 °c |
Storage temperature | -20 °c ~ 85 °c |
Product Name | FT-CJ30 |
|---|---|
Product Category | integrated sending and receiving |
center frequency | 120.0?KHz±4% |
Capacitance | 1400pF±20% |
blind area | 200mm |
Test distance (reference value) | 2m |
Direction angle (reference value) | 13°±2°(-6dB) |
Resolution (reference value) | 1mm |
Shell material | Copper shell/PC |
Operating voltage | 10-30V?DC |
Working temperature | -20 °c ~ 60 °c |
Storage temperature | -20 °c ~ 75 °c |
